• A single package of Magnaflux Sonotech UT-X
1 1

Magnaflux

UT-X Powder

UT-X Powder

SKU: 62-001

Stock Status: In stock
$27.25
$27.25
Sale Sold out
Packaging
View full details

UT-X® Powder is a cost-effective couplant powder for flaw detection and thickness gaging applications where ferrous corrosion inhibition is required.

UT-X Powder retains viscosity on salt caked boiler tubes, corroded pipe, structural steel, steel billets, welds and ship plate. Mixed with water at the inspection site, its compact and lightweight packets are easy to transport to a job site or to store as an emergency couplant for unanticipated shortages.

Benefits

  • Salt resistant
  • Environmentally benign formula
  • Fast, lump-free mixing
  • Concentrated to reduce shipping costs and storage space
  • No dyes, fragrance, or glycerin
  • Low skin irritation potential
  • Short-term corrosion protection
  • Economical option

Use Recommendations

NDT Method: Ultrasonic Testing

Required Equipment: UT equipment, transducer

Temperature Range: 32 to 120°F / 0 to 49°C

Compatibility: Most composites and metals

Defect location: subsurface

Ideal for:

  • Flaw detection
  • Thickness gauging
  • Power generating boilers
  • Corroded parts
  • Presence of corrosion, salt, or salt cake
  • Large volume flaw inspections
  • Structural steel
  • Steel billets
  • Welds
  • Ship plates

Specifications

  • API
  • ASME
  • AWS

PREPARATION INSTRUCTIONS

When mixing, be very careful to avoid adding air bubbles to the water/couplant. Use the chart below and measure water into a clean mixing container. Let water sit to remove excess air (four hours is optimum). Slowly mix packet A into water until dissolved. Mix by stirring by hand or use a drill mixer. Add packet B and continue mixing until couplant thickens, this may take several minutes.

INSTRUCTIONS FOR USE

Apply a small amount of couplant to the transducer or inspection area before measurement.

REMOVAL

Remove couplant immediately after inspection before the couplant dries with water rinse or a combination of water rinse and brushing. A difficult-to-remove film may form if the couplant is allowed to dry before removal. Remove film by pressure washing, wire brushing or immersing the part in water until the couplant rehydrates and can be washed or brushed off.

Safety Data Sheet, Packet A Safety Data Sheet, Packet B Product Data Sheet Differentiation Information
